Vibration Mill
The Vibration Mill uses a vibrator attached to a drum (grinding cylinder). The drum is partially filled with a grinding media and material to be ground and is subjected to vibrations which stir the grinding media.
The grinding force of the vibration mill is 6 to 10G compared with that of the conventional rotating ball mills, 1G. The grinding capacity become 10 to 20 times as big as that of the ball mills.
Features
-
1.Grinding times are 10 to 20 times faster than conventional rotating ball mills.
2.Wide range grinding from crushing to fine grinding.
3.Simultaneous execution of grinding, mixing and dispersion.
4.Available of both dry and wet process.
5.Free choise of lining in a grinding cylinder and media (stainless steel, alumina, zirconia, urethane, nylon, etc.).
6.Easy handling and maintenance.
7.Small installation space.
Applications
・Metal and metallic materials
・Ceramic materials
・Electric and magnetic materials, polushing materials
・Fillers, pigments and paints
・Foods
・Pharmaceuticals, cosmetics, industrial medicine
・Housing materials, energy
Applications
Metal and metallic materials
Al powder, Al-Mg powder, pure iron powder, stainless steel, WC, SCM, Copper alloy, Amourphos alloy, Metalic silica, metallic chrome, metallic magnetese, molybdenum, sponge titanium, rare-earth metals, Ferromanganese, ferrochrome
Ceramic materials
alumina, zirconium, silicon nitride, silicon carbide, black lead, fluoric aluminum, synthetic mullite, Magnesia clinker, culler, frit, fluorite, lime stome,
Electric and magnetiv materials, polising materials
Ferrite, alumina, titanic acid barium, titanic oxide, carborundum, silicon carbide, baron nitride, magnetic dioxide, antimony oxide, bastnasit, quarts, various ceramics powder, mixed grinding
Fillers, pigments and paints
Red oxide, paste, calium carbonate, organic pigment, fluorescent pigment, glass fiber carbon black, white carbon
Foods
vegetable fiber, powdered tea, green laver, gartlic powder, onion powder, mil sugar, salt, chicken feathering protein
Pharmaceuticals, cosmetics, industrial medicine
Activated charcoal, herb crude drug, herb extract. Phamaceutical, dried entails, potassium chloride, mechano-chemical effecrs of activated charcoal
Housing materials, energy
Special cement, gypsum, slaked lime, coal, reduced utanium pellet, redioactive waste ash, mountain gravel
Specifications
